Big Dog Ford Ecoboost Twin Scroll Cylinder Head

SPEED PERF6RMANC3

Big Dog Ford Ecoboost Twin Scroll Cylinder Head

(No reviews yet)

$3,400.00

SKU:: SP63-FECOTD-CYLHEAD

5 customers are viewing this product

Big Dog Ford Ecoboost Twin Scroll Cylinder Head

$3,400.00

Description

Description

Big Dog Ford Ecoboost Twin Scroll Cylinder Head

Any Idea what's an O-ring Service? If not rest assured you will after this quick read!

A head that is O-ringed simply means a groove is cut onto the head all the way around the combustion chamber. A ring is then inserted into the groove so that ONLY the rounded edge extends out from the surface. A receiver groove is then pulverized into the head. When a moldable material is used, the ring's protuberant pushes the softer copper gasket into the receiver groove mating the combustion chamber and entirely sealing it off.

This process is used to change the geometry of the seal. Rather than two flat surfaces being adhered to each other by the bolts, the material is in fact being pushed past the flat sealing surface, cutting the chamber off completely.

So, what does this mean for you? Let's find out!

Simple. This service allows for higher boost levels and minor chances of blowing the head gasket.

____________________________________________________________________________

Competition Valve Job

What the he*k is this?

A competition valve job is a simple way to help you gain more horse power.

This process is a 3 or 5 angle valve job, and consists of lowering the position of the valve seal sitting area that you would typically find in a standard valve job. By doing so the valve seals better and creates more power.

So how will this get you more power?

Well it is fairly simple to understand. When you lower the area where the valve sits you create a larger hole which allows more fuel and air to enter the cylinder head. Hence, creating more horse power.

-Valve Seat Position-

A competition valve job is more than just 3 or 5 angles. The width and positioning of the 45-degree seat angle is crucial for the intake valve. Builders often prefer to position the seat as elevated (toward the combustion chamber) on the valve as possible.

In exhaust valves the majority of engine builders prefer to position the valve seat towards the center of the valve. Why you ask? Exhaust valves typically function much hotter than intake valves therefore, positioning the valve seat lower increases the longevity of the scorching exhaust valves.

____________________________________________________________________________

Product Includes

CNC Single Runner w/ CNC Bowl Work
Manley 85lbs Beehive Style Valve Springs
Piper BP285 Camshafts
O-Ring Service / Copper Wire
5 Angle Competition Valve Job
SP63 High Performance Assembly
Shipping Included
